Columbus Time Touch AIR
Columbus Time Touch Air is used for closed rooms/halls – the revolving doors control the light function and creates the pressure wave. 2-wire – no neutral. The automatic timer or staircase switch – for communal areas– You can repeat, reset and turn on/off. Works isolated or with pneumatic or electronic Columbus timers. 3 sensitivity levels – L = low H = high M = medium – depending on the area. Default = M. Extensive coverage of 700m3. 1 unit is enough for a whole stairway!Comfort is a top priority.Greater security.No ‘dead’ angles. Built-in fixed lux-sensor.Time adjustment of 1-30 min. Fits into original Columbus wall box surface, wall box Europe + British standard box.
Included in the box. All wiring should be carried out by a qualified Electrician in accordance with the current regulations.
Stairwells, Corridors, Basement, Storeroom, Toilets, Laundry/Drying Room, Lift Room.
x1 Light Switch.
|Load Rating||16A/250V~ and 50Hz for all load types|
|Compatible||With 16 mm deep single gang BS accessory plate|
|Colour||White RAL 9010|
|Power Dissipation||< 0,3 w|
|Temperature||0°C - +50°C|
|Air Humidity||5% - 95% RH|
|Terminals||2 x 2,5 mm²|
|Timing: TS-TT20AIR||1 min - 30 min|
|Product||No.per Pack||Type||Time Delay||Mounting|
|TS-TT20AIR||x1||2 pole, 2 wire||> 10 min||20mm & 25mm deep boxes|
