E1WF Hazardous Area Gland Kit (Peppers)
Peppers “E” type double compression glands are certified Flameproof Ex db, Increased Safety Ex eb, Restricted Breathing Ex nR and Dust Protected Ex ta. They are suitable for use in Zone 1 and 2 for Gas Groups IIA, IIB and IIC and additionally for use in Zones 20, 21 and 22 for Dusts Groups IIIA, IIIB and IIIC. Also certified for Zone and Division installations for use with Marine Shipboard and Tray Cables under the NEC and CEC. They provide a controlled Ex db & IP seal on the cable inner sheath, an environmental seal on the outer sheath and a detachable armour specific clamping system for wire (W), braid/tape (X) armoured cables. The gland has been tested to IP66 and IP68 to 50 metres. The Integral Earth “IE” version allows the gland to be used with HV cables where the fault load is greater than 10.4kA and options are available for use with lead sheath, LSOH cables and extreme temperature applications.
Features & Benefits
• Hazardous Area Approved
• Ex d, Exe and Ex nR certified
• Suitable for use in Zone 1, Zone 2, Zone 21 and Zone 22
• Gas Groups IIA, IIB, and IIC
• For use with SWA (steel wire armoured) cable
• IP66 ingress protection
• Industry standard M20 and M25 metric thread
Hazardous area approved cable glands are intended for use in areas where there is a greater risk of explosive gasses present. Some of the most common environments are:
• Oil & Gas Plants
• Food & Beverage Sites
• Weatherproof Warning Lights & Beacons
• Electrical Enclosures
• Door Entry Systems
Directions for Use
Indoor / Outdoor Applications.
The Peppers E type cable glands are protected to IP66 which means they are dust-tight and protected against powerful jets of water from all directions. They are ideal for harsh environments, outdoor applications and areas with a higher level of sealing and protection are required.
Brass, Aluminium or Stainless Steel.
Brass or Silver Metal.
IP66 + IP68 (50 metres – 7days) type 4X
|Hazardous Area Certification||
ATEX, UKEX, IECEx + more, see datasheet
|Max. Operating Temp.||
|Min. Operating Temp.||-35°C|
|Peppers Part No.||E1WFK2/16/M20||E1WFK2/20S/M20||E1WFK2/20/M20||E1WFK2/25/M25||E1WFK1/32/M32||E1WFK1/40/M40||E1WFK1/50/M50||E1WFK1/63/M63||E1WFK1/75/M75|
|No. per Pack||x2||x2||x2||x2||x1||x1||x1||x1||x1|
|Cable Range (mm)||8.4 - 13.5||11.5 - 16.0||15.5 - 21.1||20.3 - 27.4||26.7 - 34.0||33.0 - 40.6||45.7 - 53.2||58.4 - 65.8||71.1 - 78.0|
|Entry Thread - D (mm)||M16 x 1.5||M20 x 1.5||M20 x 1.5||M25 x 1.5||M32 x 1.5||M40 x 1.5||M50 x 1.5||M63 x 1.5||M75 x 1.5|
|Entry Thread - E (mm)||16||16||16||16||16||16||16||19||19|
|Armour ⌀ (mm)||0.9||0.15 - 1.25||0.15 - 1.25||1.25/1.6||1.6/2.0||1.6/2.0||2.0/2.5||2.0/2.5||2.5/3.0|
|Approx. Length from Shoulder - F (mm)||58.0||58.0||58.0||58.0||65.0||72.0||73.0||76.0||82.0|
|Hexagon Across Flats - G (mm)||24.0||24.0||30.0||37.6||46.0||
|Hexagon Across Corners - H (mm)||
